Metal to Metal Trunnion Mounted Ball Valve

Metal to Metal Trunnion Mounted Ball Valve

Product Description

The Metal to Metal Trunnion Mounted Ball Valve is a high-performance valve that is widely used in various industries.

It features a trunnion-mounted ball design, which means the ball is supported by trunnion bearings on both ends, allowing for smooth and reliable operation even at high pressures and temperatures.

The body of the Metal to Metal Trunnion Mounted Ball Valve is typically made of carbon steel or stainless steel, ensuring excellent strength and corrosion resistance.

The valve is designed to withstand harsh conditions and can handle abrasive and corrosive media.

One of the key features of the Metal to Metal Trunnion Mounted Ball Valve is its metal-to-metal sealing mechanism.

This type of sealing provides a secure and tight closure, preventing leakage even in high-pressure applications. The metal sealing also ensures durability and long service life.

The ball valve has a full bore design, meaning the ball port is the same size as the pipeline, allowing for unobstructed flow and minimal pressure drop.

This design is particularly suitable for applications that require high flow capacity and low resistance.

The Metal to Metal Trunnion Mounted Ball Valve offers excellent shut-off capabilities, providing a bubble-tight seal to prevent any unwanted flow.

It can be operated manually or actuated, depending on the specific application requirements.

Furthermore, the Metal to Metal Trunnion Mounted Ball Valve is easy to maintain and repair.

It is designed with a two-piece body construction, allowing for easy access to internal components for inspection and maintenance. This design also facilitates quick and efficient repairs, minimizing downtime and maximizing productivity.

In conclusion, the Metal to Metal Trunnion Mounted Ball Valve is a reliable and high-performance valve suitable for a wide range of applications.

Its trunnion-mounted ball design, metal-to-metal sealing, full bore construction, and easy maintenance make it an ideal choice for industries such as oil and gas, petrochemical, power generation, and more.

TRUNNION MOUNTED BALL VALVE Standard features
Double block-and-bleed capability
Metal-seated, trunnion-mounted design

Design Specifications

Design Standard: API 6D, ASME B16.34, ISO 14313, ISO 17292
Size Range: 2”~36” (50mm~200mm)
Pressure and Temp. Range: ASME B16.34.
End Connections: Flange, Butt Weld *
Inspection and Testing: API 598 test with no visible leakage
Butt Weld Ends: ASME B16.25,
Face to Face Dimensions: ASME B16.10.
